They use 12nm ASIC solution, equipped with a 3840x2160 resolution 50fps BSI CMOS sensor which has low illumination and high sensitivity.It can be used in scope, handheld portable devices and etc fields.
● BSI NIR CMOS sensor IMX678/IMX585
● Optical Format:1/1.8，1/1.2
● Resolution:3840x2160
low illumination high sensitivity sensor
Excellent image quality
Supports Wi-Fi,Built-in 64GB Memory
Supports photography and Recording
Integrated 4x GPIO Buttons and Rotary Encoder
Reserved Laser Range Finder Connector
| Model | LC220-CS-4K | ||
Detector | Detector Type | BSI NIR CMOS | |
| Detector Type | IMX678 | IMX585 | |
| Resolution | 3840x2160 | ||
| Optical Format | 1/1.8” | 1/1.2” | |
| Pixel Size | 2μm | 5.96μm | |
| Frame Rate | 25Hz/50Hz | ||
IOS | 0.01 Lux | 0.0001 Lux | |
| Image Adjustment | Exposure Compensation | Supported | |
Image Mode | Day/Dusk/Night | Color | |
| Denoise | Contrast/Sharpness/Brightness | ||
| Main Function | Wi-Fi+Recording and Capture | Supported | |
Motion Sensor+Compass+PIP | Supported | ||
Reticle | On/Off/Adjust | ||
Digital Continue Zoom | 4.0~16.0× | ||
Video Format | MP4 | ||
Picture Format | JPG | ||
Storage | 64G | ||
| Voltage Current | Battery Voltage | 4.2V/4.35V | |
| Charging Current | 500mA@5V | ||
| GPIO/TTL Voltage | 3.3V | ||
| Power Supply | USB Charge/Battery | ||
| Battery | 1S-Li(5H) | ||
| Connector | Wi-Fi Antenna Connector | First generation | |
| Panel Connector | BOE 0.39, 1920x1080@50Hz | ||
| Rotary Encoder | Supported | ||
| Battery Connector | Supported | ||
| USB Port | Supported | ||
| GPIO Buttons | Supported | ||
| Lens | M34 x 0.75 | ||
| Physical Property | Weight(No lens) | / | |
| Dimension(No lens) | 42 x 42 x 26 mm | ||
| Environment Adaptability | Operating Temperature | -20℃~60℃ | |
| Storage Temperature | / | ||
| Humidity | / | ||
