LC220-Mono series were star light night vision module that developed by Link-Card Tech,They use ASIC solution, equipped with a 1280x1024 or 800x600 resolution BSI CMOS image sensor with 9.76μm x 9.76μm pixel size
● 1”optical format, ultra-low noise CMOS image sensor
● Supports HD OLED/HDMI/SDI/TVI/CVI/CVBS/AHD output
● Integrated Compass and Motion Sensor
low illumination high sensitivity sensor
Excellent image quality
Supports Wi-Fi,Built-in 64GB Memory
Supports photography and Recording
Integrated 4x GPIO Buttons and Rotary Encoder
Reserved Laser Range Finder Connector
| Model | LC220-Mono-SXGA | LC220-Mono-SVGA | |
Detector | Detector Type | BSI NIR CMOS | |
| Resolution | 1280x1024 | 800x600 | |
| Optical Format | 1.0” | 1.0” | |
| Pixel Size | 9.76μm | 16μm | |
| Frame Rate | 25Hz/30Hz/50Hz/60Hz | ||
IOS | 0.0001 Lux | ||
| Image Adjustment | Exposure Compensation | Supported | |
Image Mode | Black&White | ||
| Denoise | 2D,3D | ||
| Main Function | Wi-Fi+Recording and Capture | Supported | |
Motion Sensor+Compass+PIP | Supported | ||
Reticle | On/Off/Adjust | ||
Digital Continue Zoom | 4.0~16.0× | ||
Video Format | MP4 | ||
Picture Format | JPG | ||
Storage | 32G(Customizable) | ||
| Voltage Current | Battery Voltage | 4.2V/4.35V | |
| Charging Current | 500mA@5V | ||
| GPIO Voltage | 3.3V | ||
| TTL Level | 3.3V | ||
| Power Supply | USB Charge/Battery | ||
| Battery | 1S-Li(5H) | ||
| Connector | Wi-Fi Antenna Connector | First generation | |
| Image Output | BT656/BT1120/RGB888 | ||
| Rotary Encoder | Supported | ||
| Battery Connector | Supported | ||
| USB Port | Supported | ||
| GPIO Buttons | Supported | ||
| Lens | M34 x 0.75 | ||
| Physical Property | Weight(No lens) | 27g | |
| Dimension(No lens) | 32 x 32 x 22 mm | ||
| Environment Adaptability | Operating Temperature | -20℃~60℃ | |
| Storage Temperature | / | ||
| Humidity | / | ||
