A1D-X-2MP series were industrial color low-light camera that developed by Link-Card Tech, include HDMI, SDI and AHD/TVI/CVBS/CVI three modules.
● BSI NIR CMOS sensor SC2210/IMX482
● Supports Auto/Manual Calibration, Reticle, Digital Zoom, Integrated Compass and Motion Sensor
● HDMI/AHD/SDI +USB (UVC driver-free) output
low illumination, low consumption and high sensitivity
Excellent image quality
Integrated GPIO Button for adjustment
High integration, small size, low consumption
5V DC, Type-C port
HDMI/AHD/SDI +USB (UVC driver-free) output
| Model | A1D-X-2MP | ||
Detector | Detector Type | BSI NIR CMOS | |
| Detector Model | SC2210 | IMX482 | |
| Resolution | 1920 x 1080 | ||
| Optical Format | 1/1.8 | 1/1.2 | |
| Pixel Size | 4μm | 5.96μm | |
| Frame Rate | 25Hz/50Hz | ||
| IOS | 0.0001 Lux | ||
| Image | Exposure Compensation | Supported | |
| Image Mode | Day/Dusk/Night | Color | |
| Color Adjust | Supported | ||
| Function | Motion Sensor+Compass+PIP | Supported | |
| Digital Continue Zoom | 4.0~16.0× | ||
| Button | Up, Down, Left, Right, Menu button | ||
| Output Port | A1D-HDMI-2MP | HDMI，Type-C | |
| A1D-AHD-2MP | MCX，Type-C | ||
| A1D-SDI-2MP | MCX，Type-C | ||
| Output Resolution | A1D-HDMI-2MP | 1920 x 1080 | |
| A1D-AHD-2MP | 1920 x 1080 | ||
| A1D-SDI-2MP | 1920 x 1080 | ||
| USB Output | USB（UVC）Output Resolution | 1920 x 1080 | |
| Electrical Parameters | Power Port | USB Type-C | |
| Power Supply | 5V DC | ||
| Power Consumption | ≤2W | ||
| Other | Lens | M29 x 0.5 | |
| Dimension(No lens) | 32 x 32 mm | ||
| Weight(No lens) | / | ||
| Operating Temperature | -20℃~60℃ | ||
| Storage Temperature | / | ||
| Humidity | / | ||
